ORTOFON MC QUINTET MONO Expand

ORTOFON MC QUINTET MONO

Ortofon Ortofon

Ny

6 990 kr

inkl.

The Quintet Mono is a new true Mono from Ortofon.

It features Nude Elliptical r/R 8/18µm stylus that is a good solution for playing mono microgroove vinyl records. The Quintet Mono will track perfectly through even worn and damaged records and ensure the surface noise control.
Quintet Mono uses a strapped output to deliver the same output signal from both sets of pole pins. This effectively eliminates the need for mono-specific equipment, making it possible to enjoy true mono reproduction on any stereo playback system.

Quintet Mono is the best cartridge in the Quintet series to play monophonic records.

  • Output voltage at 1 kHz 5 cm/sec - 0.3 mV
  • Frequency range at -3dB - 20-25.000 Hz
  • Frequency response - 20 Hz - 20 kHz +/-2.0 dB
  • Tracking ability at 315 Hz at recommended tracking force *) - 70 μm
  • Compliance, dynamic, lateral - 15 μm/mN
  • Stylus type - Nude Elliptical
  • Stylus tip radius - r/R 8/18 μm
  • Tracking force range - 2.1-2.5 g (21-25 mN)
  • Tracking force recommended - 2.3 g (23 mN)
  • Tracking angle - 20º
  • Internal impedance, DC resistance - 5 Ohm
  • Recommended load impedance - >20 Ohm
  • Cartridge body material - ABS/Aluminium
  • Coil wire material - Pure 4-nines silver/Ag
  • Cartridge colour - White
  • Cartridge weight - 9 g
